The Acue Lighting Legend 230 Mini Moving Head has become the new standard of beam moving heads. It is the miniature version of our full size Legend 230. The Acue 7R Mini Beam Double Prism Moving Head features a 230w 7R lamp as its light source (2000 hrs), 13 colors/white, 14 gobos/open, 7 facet linear and 24 facet circular rotating prisms, mechanical linear dimmer, mechanical focus control, mechanical linear frost filter control and mechanical shutter control. The Acue 7R Mini Beam Double Prism Moving Head features super fast and precise motor speed and positioning. The Acue 7R Mini Beam Double Prism Moving Head has become one of the most asked for fixture for all production/lighting companies. It is a perfect choice for permanent installations and production rental applications.
The Acue 7R Mini Beam Double Prism Moving Heads are sold in packages only which include 2 fixtures, a 2-in 1 heavy duty road case, clamps, brackets and safety cables.
| Light Source |
230W 7R Lamp (2000hrs.) |
| Operating Modes |
DMX, Auto-Program, Sound-Active |
| DMX Channels |
17 Channels 3-pin DMX in/out |
| Pan |
540° |
| Tilt |
270° |
| Gobo Wheel |
17 Gobos + open |
| Color Wheel |
13 Colors + open |
| Dimmer / Shutter |
0-100% Linear dimmer control by DMX, Shutter strobe speed adjustable by DMX |
| Prism |
7 Facet Linear & 24 Facet Circular rotating prisms with overlapping option. |
| Focus |
Focus adjustable by DMX control |
| Total Power Draw |
260 Watts |
| Input Voltage |
110-220V AC 50/60Hz |
| IP Rating |
IP 20 (indoor use only) |
